Microcontroller: 32-Bit (RP2040)

Inputs (28 IN);
18x I/Os in a minimal form factor
6x Analog Inputs (24 Bits resolution)
4x Analog or Digital Inputs (12 Bits resolution)

Outputs (8 OUT):
8x Outputs (Half Bridge, max. 3A per channel, PWM)
Built-in Current Sensor for output current monitoring
Adjustable output current limit from 0.5A to 3A

Cryptography: ECC608 Crypto Chip
Communication: RS485 or CAN
Networking: Ethernet Port with W5500 from Wiznet

With our new screwless terminal block plugs, you are getting a way easier method of connecting wires to the pin headers, without the need to use classic jumper wire cable connectors. A pure cable is enough. Plus: The block plugs guarantee a high retention of the wire as well as optimal contact.

The installation of the screwless terminal block plugs is easy too:

Place the included pin header adapter into the pin headers. Push them slightly into This guarantees that you will use the right orientation.
Plug in the screwless terminal block plug into the pin header.
Push down the orange button and press the cable into the screwless terminal block plug.

Powered from 12Vdc to 24Vdc
Ethernet (RJ45, 10/100Mbps)
RS485
Inputs (21 IN):
16x Analog (0-10Vdc) / digital (24Vdc)
5x Digital Input / interrupt.
Outputs (40 Out):
16x Relay Outputs
24x Digital Outputs

Powered from 12Vdc to 24Vdc
Ethernet (RJ45, 10/100Mbps)
RS485
Inputs (21 IN):
16x Analog (0-10Vdc) / digital (24Vdc)
5x Digital Input / interrupt.
Outputs (40 Out):
16x Relay Outputs
24x Digital Outputs

Powered from 12Vdc to 24Vdc
Ethernet (RJ45, 10/100Mbps)
RS485
Inputs (12 IN):
10x Analog (0-10Vdc) / digital (24Vdc)
2x Digital Input / interrupt.
Outputs (17 Out):
5x Relay Outputs
12x Digital Outputs

Powered by 24Vdc
Ethernet (RJ45, 10/100Mbps)
Inputs (20 IN):
12x Analog (0-10Vdc) / digital (24Vdc)
4x Digital Input
2x Fixed Digital Input / interrupt.
2x Fixed Analog Input (0-10Vdc / 0-20 mA)
Outputs (22 Out):
5x Relay Outputs
8x Digital Outputs
2x Fixed Analog Outputs (0-10Vdc / 0-20mA)

Powered by 24Vdc
Ethernet (RJ45, 10/100Mbps)
Inputs (20 IN):
12x Analog (0-10Vdc) / digital (24Vdc)
4x Digital Input
2x Fixed Digital Input / interrupt.
2x Fixed Analog Input (0-10Vdc / 0-20 mA)
Outputs (18 Out):
10x Relay Outputs
8x Digital Outputs

Powered by 24Vdc
Ethernet (RJ45, 10/100Mbps)
Inputs (20 IN):
12x Analog (0-10Vdc) / digital (24Vdc)
4x Digital Input
2x Fixed Digital Input / interrupt.
2x Fixed Analog Input (0-10Vdc / 0-20mA)
Outputs (22 Out):
10x Relay Outputs
8x Digital Outputs
2x Fixed Analog Outputs (0-10Vdc / 0-20mA)

Powered from 12Vdc to 24Vdc
Ethernet (RJ45, 10/100Mbps)
RS485
Inputs (12 IN):
10x Analog (0-10Vdc) / digital (24Vdc)
2x Digital Input / interrupt.
Outputs (22 Out):
10x Relay Outputs
12x Digital Outputs

Powered from 12Vdc to 24Vdc
Inputs (12 IN):
10x Analog (0-10Vdc) / digital (24Vdc)
2x Digital Input / interrupt.

Outputs (22 Out):
10x Relay Outputs
12x Digital Outputs

Communications
Ethernet (RJ45, 10/100Mbps)
RS485

Powered from 12Vdc to 24Vdc
Inputs (8 IN):
4x Analog (0-10Vdc) / digital (24Vdc)
2x Digital Input
2x Analog Input
Outputs (14 Out):
6x Relay Outputs
8x Digital Outputs (parallel to digital, galvanic ins.)

Powered from 12Vdc to 24Vdc
Inputs (8 IN):
4x Analog (0-10Vdc) / digital (24Vdc)
2x Digital Input
2x Analog Input
Outputs (14 Out):
6x Relay Outputs
8x Digital Outputs (parallel to digital, galvanic ins.)
