How to connect industrial Raspberry PLC to Wi-Fi

Industrial Communications

Odoo image and text block

  Introduction


Raspberry Pi based PLC family devices have Wi-Fi wireless connectivity by default.

It uses the two most common frequencies: 2.4GHz and 5GHz. It also uses the IEEE 802.11.b/g/n/ac bands. And, to connect them to the Wi-Fi network, you have to follow some specific steps.

Requirements

The key points to consider are as follows:

 Related links

Basics about digital outputs of a Raspberry Pi automation PLC
Read >>

Basics about Raspberry Pi PLC analog outputs
Read >>

How to find your perfect industrial PLC
Read >>

How to program open source PLC Raspberry Pi interrupt inputs with Python

Read >>

Raspberry PLC family products
Read >>


 Explanation

To connect this PLC with your Wi-Fi network, you must modify the wpa_supplicant file inside the Raspberry:

sudo nano /etc/wpa_supplicant/wpa_supplicant.conf

And you must configure the file with the configuration parameters of the Wi-Fi network (it may change depending on the specific configuration of each case):

ctrl_interface=DIR=/var/run/wpa_supplicant GROUP=netdev
update_config=1
country=GB

network={
ssid="NETWORK SSID"
psk="NETWORK PASSWORD"
key_mgmt=WPA-PSK
}

And that is all, after that you must restart the networking services to apply the changes:

sudo service networking restart


Or you can reboot the system to apply the changes:

sudo reboot
