Industrial Panel PC based on Raspberry Pi
Automation based on Open Source Hardware
Industrial Solutions for monitoring and control your machines, production lines, installations.
Monitoring and Control solutions
This resistive Panel PC is based on GNU/Linux OS installed on an SD card. It has many interfaces built in: Ethernet, USB, WiFi...
- Quad-Core ARM Cortex-A72 1.5GHz
- Linux Raspberry / Ubuntu
Do you need more information?
Tell us what do you expect, what more do you need to know, and we will try to solve all your questions.
Please, fill the form below, send us an email at firstname.lastname@example.org, or call us at +34 938 760 191
Resistive Multitouch LVDS, 315 nits
1280x720, 170º viewing angle, format 16:9
Operates at 0º to 40ºC, also between 10% and 90% humidity
Quad-Core ARM Cortex-A72 1.5GHz
Broadcom VideoCore VI, OpenGL ES 2.0, MPEG-2 and VC-1(license) H.265 (4kp60 decode), H264 (1080p60 decode, 1080p30 encode)
(2) Port x 2.0
(one of them is used for the touch screen)
(2) Port x 3.0
SD / MMC / SDIO slot
Gigabit Ethernet – Serial TTL
Wireless LAN / 2.4 GHz and 5.0 GHz IEEE 802.11ac wireless, Bluetooth 5.0, BLE
10x GPIO, SPI, I2C, UART
Linux Raspbian / Ubuntu
From 3,3 to 24V
Panel PC based details
Industrial Automation with the new Raspberry Pi 4 Model B
This Panel PC is based on GNU/Linux (Raspbian/Ubuntu) OS installed on an SD card. It has many interfaces built in: Ethernet, USB, WiFi...
Using the Ethernet port or WiFi network you can remotely control all parameters, data and inputs/outputs of your control system.
Furthermore, Touchberry PI comprises enough I/Os to replace PLCs on simple automation applications.
Open protocols not only allow communication with other Industrial Shields PLCs, but also third-party devices and machinery.
In complex systems, you can create a network between several TOUCHBERRY PI. Providing integral supervision and control solution for entire production plants and real-time data at hand.
EASY SETUP AND INSTALLATION
It complies with regulations for industrial automation.
Connect external memory card or copy your important data using usb.
Choose your OS
